WHAT'S
NEW IN





SEAMLESS, OPTIMIZED MOLD DESIGN


New ECO Application
Highly effective assessment and seamless incorporation of any number of
engineering changes into an existing model with the new ECO application.

Cap Internal Islands
Dramatically reduced user design time with the fast creation of the internal parting surface
Watch the video


Lifter Pocket
Easy pocket creation for lifters during the parting design or tool design stages with the click of a button.
Watch the video


Cooling Design
Speedy baffle creation, enhanced cooling channel design, and improved channel analysis.

Watch the video


Modeling
Faster work and greater flexibility with new and enhanced features in solid and faces,
including new extrude and cut functionalities, shadow taper, warp faces, enhancements
to trim and split, and more.

Sketcher
Enhanced user experience with automatic reference and clearer constraints on screen.

Drawing
Faster creation of detailed drawings with new capabilities such as automatic center line
and automatic hole and thread attributes.










Cimatron enables us to do our design work
better and faster. It makes us more productive -
we can do more business with the same resources.

C&C DESIGN, USA
